LBP Board 2192

Temperature Grade

1200℃ (2192℉)

Chemistry

Silicon, calcium, magnesium (AES)

CCEWOOL® Low Biopersistent Fiber Board 2192 is primarily composed of alkaline earth silicate (AES) fibers. It is soluble and biodegradable in human body fluids, making it harmless to both humans and the environment. It is truly a green and environmentally friendly product.

Get a Quote

CCEWOOL® LBP Board 2192

CCEWOOL® Low Biopersistent Fiber Board 2192 is a soluble fiber board made from a mixture of organic and inorganic binders, with a very low Fe2O3 content.

Our CCEWOOL® Low Biopersistent Fiber board 2192 can come into direct contact with fire and can be cut into various sizes according to customer requirements. It has an extremely low thermal conductivity, low heat storage capacity, and excellent resistance to thermal shock, making it suitable for applications with large temperature variations.

Benefits

  • Ultra-Low Shot Content

    Shot content is a crucial factor in determining the thermal conductivity of fibers. Using a unique shot removal process, our fibers achieve ultra-low shot content, demonstrating excellent thermal performance with low thermal conductivity and superior insulation properties in continuous high-temperature environments.

  • Minimal Shrinkage Rate

    Strict control of harmful impurities is essential for reducing thermal shrinkage and enhancing heat resistance. Through rigorous raw material management, we reduce impurity content to below 1%, ensuring low thermal shrinkage and high heat resistance in our fiber boards.

  • Strongest compressive strength

    Compressive strength refers to the fiber board's ability to resist breaking under pressure. Using a fully automatic drying system, the drying process is faster and more thorough, achieving deep drying in 2 hours with uniform results. This ensures the product has superior compressive strength.

  • Lowest Thermal Conductivity

    Through strict quality control and high-standard production processes, CCEWOOL® minimizes shot content and meticulously controls bulk density, achieving the lowest thermal conductivity. This provides customers with exceptional insulation performance and more efficient energy-saving solutions.

Features of Low Biopersistent Fiber Board 2192

  • Low thermal conductivity

    The board exhibits minimal heat transfer ability, providing effective insulation against thermal energy.

  • Low thermal storage

    It has a reduced capacity to retain heat, contributing to efficient thermal management in applications.

  • High tensile strength

    The board possesses strong resistance to tensional forces, ensuring durability and structural integrity.

  • Thermal shock resistance

    It withstands rapid changes in temperature without cracking or deteriorating, maintaining performance under varying thermal conditions.

  • Lightweight

    The board is lightweight, facilitating ease of handling and installation while minimizing structural load.

  • Excellent corrosion resistance

    It demonstrates strong resilience against corrosion, enhancing longevity and reliability in harsh environments.

Application of Low Biopersistent Fiber Board 2192

Advanced Solutions for High-Temperature Furnace Lining and Insulation

Hot face lining for furnace and oven;
Flue & chimney linings in furnaces & kilns;
Insulating backup for these products:
- Fire brick
- Insulating brick
- Refractory castable;
Insulation for electric appliance and heat treatment.

Specifications & Sizes

CCEWOOL® LBP Board 2192

Classification Temperature (℃ ) 1200℃(2192℉)
Color Light Bluish
Density (kg/m³) 300
Modules of Rupture (MPa) ≥0.25
Compressive Strength (MPa, 10% relative deformation) 0.15
Loss of Ignition (%) ≤7
Permanent Linear Shrinkage (%) 1100℃ x 24h ≤2.0
Thermal Conductivity (W/m·K)
200℃ 0.05
400℃ 0.08
600℃ 0.1
800℃ 0.12
1000℃ 0.14

Custom size are available.Contact Us
