Superbloc® Module

Temperature Grade

1316°C (2400°F), 1430°C (2600°F)

Chemistry

Alumina, Silica

CCEWOOL® Superbloc® Module is a brand-new high-end offering from CCEWOOL® and is unique in its application in ceramic fiber linings.

Get a Quote

CCEWOOL® Superbloc® Module

CCEWOOL® Superbloc Module is a block-shaped, integrated fiber module made from high-purity synthetic materials. It is produced on a fully automated, continuously controlled production line using ceramic fiber cotton blocks.

CCEWOOL® Superbloc Module is installed using new, specialized anchors and installation tools to ensure high compression pressure between the modules. This allows for easy and quick installation, secure positioning, and safe structural integrity.

This product is a brand-new high-end offering from CCEWOOL® and is unique in its application in ceramic fiber linings.

Benefits

  • Ultra-Low Shot Content

    Shot content is a crucial factor in determining the thermal conductivity of fibers. Using imported high-speed centrifuges, our fibers achieve ultra-low shot content, demonstrating excellent thermal performance with low thermal conductivity and superior insulation properties in continuous high-temperature environments.

  • Minimal Shrinkage Rate

    Strict control of harmful impurities is essential for reducing thermal shrinkage and enhancing heat resistance. Through rigorous raw material management, we reduce impurity content to below 1%, ensuring low thermal shrinkage and high heat resistance in our fiber modules.

  • Maximum Tensile Strength

    Tensile strength refers to the fiber module's ability to resist breaking under tension. The fiber blanket is folded according to specifications and compressed with a 5t press, then packaged under compression. It has excellent elasticity, effectively withstanding impacts in harsh environments and significantly extending its service life.

  • Lowest Thermal Conductivity

    Through strict quality control and high-standard production processes, CCEWOOL® minimizes shot content and meticulously controls bulk density, achieving the lowest thermal conductivity. This provides customers with exceptional insulation performance and more efficient energy-saving solutions.

Features of Superbloc® Module

  • Multi-directional compression

    It can be compressed in any direction, allowing for full expansion in the installation direction of the furnace lining, resulting in excellent insulation performance.

  • Completely seamless structure

    After calcination, the product transforms from a soft, compressible block into a high-strength, seamless, and firm structure, offering high integrity and durability.

  • High temperature, low shrinkage

    The cold face of the product can closely adhere to the furnace wall, maximizing compression between modules, ensuring low shrinkage at high temperatures, and maintaining structural integrity.

  • Customization

    Suitable for a wide range of flat structures and for cutting and installing shaped components. Various shaped products can be manufactured according to the different shapes of equipment.

Application of Superbloc® Module

High-Performance Insulation Solutions for Industrial High-Temperature Applications

Insulation for high-temperature furnaces.
Surface insulation of industrial kilns.
Fire-barrier material for the multi-temperature-zones furnace.
Backing insulation of petroleum, chemical, and metallurgical furnace.
High-temperature sintering sagger.
High temperature sealing for machine and precision mold.

Specifications & Sizes

CCEWOOL® Superbloc® module

Description Superbloc® Module 24 Superbloc® Mlodule 26
Classification Temperature (℃ ) 1316(2400℉) 1430(2600℉)
Color White White
Shot Content (%) ≤10 ≤10
Density (kg/m°) 160 192 240 160 192 240
Permanent Linear Shrinkage (%) 1200℃x24h≤3 1400℃x24h≤3
Thermal Conductivity (W/m-K)
400℃ ≤0.09 ≤0.09
600℃ ≤0.14 ≤0.14
800℃ ≤0.20 ≤0.20
1000℃ - ≤0.28
Standard Size (mm) Length 305
Width 305
Thickness 76-305

Custom size are available.Contact Us
